CONCEPT
SHOULDER HAND INSTRUMENTS

In arthroscopic surgery, meniscus, cartilage, ligaments and bones are to be treated depending on the clinical situation.
Often, tissue fragments need to be separated or removed from the joint.


To facilitate these arthroscopic treatments, Medacta provides a comprehensive choice of arthroscopic hand instruments:
Punches, Graspers, soft tissue Penetrators and Suture Cutters.

PRODUCT RANGE

Individual instruments used for gripping tissue during arthroscopic interventions. Designed to be utilized for: removing loose meniscal tissue, removing of mainly detached cartilage flaps, removing of mainly detached osteophytes, gripping and carrying of suture during arthroscopic reconstruction techniques.
Available with or without Locking System (L. S.).

LOOSE BODY GRASPER

Toothed Tip: straight, width 4 mm
Straight Shaft: Ø4 mm, L 125 mm
Forceps Handle with Cleaning System

GRASPER FORCEPS

  • Toothed Tip: straight, width 4 mm
    Straight Shaft: Ø4 mm , L125 mm
    Forceps Handle with Cleaning System
    and Locking System
  • Toothed Tip: straight, width 4 mm
    Straight Shaft: Ø4 mm, L 125 mm
    Forceps Handle with Cleaning  System
    W/O Locking System

Individual instruments used for piercing soft tissue and for carrying suture through soft tissue.

SUTURE PASSER RIGHT

Right Hooked Tip: width 3,5 mm
Straight Shaft: Ø4 ,L 155 mm
Wishbone Handle Green

SUTURE PASSER LEFT

Left Hooked Tip: width 3,5 mm
Straight Shaft: Ø4 ,L 155 mm
Wishbone Handle Red

SUTURE PASSER RIGHT

Bent Tip: width 2,5 mm
Straight Shaft: Ø4  mm, L155 mm
Axial Handle Green

SUTURE PASSER LEFT

Bent Tip: width 2,5 mm
Straight Shaft: Ø4  mm, L155 mm
Axial Handle Red

Individual instruments used to push knots up to the desired location and to cut sutures during arthroscopic interventions.
The open tip configuration allows for side suture loading within the instrument. The closed tip configuration allows for frontal suture insertion outside the joint improving the stability of the instrument sliding over the suture.

SUTURE CUTTER

  • Open Tip: width 4,2 mm
    Straight Shaft: Ø4 mm, L 165 mm
    Forceps Handle with Cleaning System
  • Open Tip: width 4,5 mm
    Straight Shaft: Ø3 mm L 165 mm
    Wishbone Handle
  • Open Tip: width 4,5 mm
    Straight Shaft: Ø3 mm, L 165 mm
    Forceps Handle

SUTURE CUTTER

  • Closed Tip: width 4,5 mm
    Straight Shaft: Ø3 mm, L 165 mm
    Wishbone Handle
  • Closed Tip: width 4,5 mm
    Straight Shaft: Ø3 mm, L 165 mm
    Forceps Handle
CLEANING FEATURES

All Medacta hand instruments feature an integrated cleaning mechanism achieved through implementation of side
fenestrations (a) that allow access to all hidden surfaces.



Some Punches, Graspers and Suture Cutters allow partial disassembly of the hand-piece during the washing process. The following images show how to assemble/disassemble Medacta Hand Instruments for cleaning and washing.



For detailed information see the Product Catalogue (ref: 99.101.180)
